1 / 10UV Municipal Series — 20000 to 200000 LPH
Large-scale municipal UV disinfection 20,000–2,00,000 LPH — amalgam lamp, open channel and closed vessel
UV Municipal Series 20,000–2,00,000 LPH by Ozone India Technology, Ghaziabad. High-output amalgam UV lamps in closed-vessel SS316 or open-channel configuration. US EPA UV Guidance Manual compliant. For drinking water plants, STP tertiary, ETP reuse.
High-output amalgam UV systems for municipal drinking water, STP tertiary treatment, and large industrial water treatment plants. Available in closed-vessel (pressure pipe) and open-channel configurations. Amalgam lamps deliver 3× higher UV output than standard low-pressure lamps and maintain output across wide water temperature range. Each system CFD-validated for flow uniformity. Complies with US EPA UV Disinfection Guidance Manual (UVDGM) for Cryptosporidium and Giardia control.
| Flow Rate | 20,000 LPH to 2,00,000 LPH |
|---|---|
| UV Lamp Type | Amalgam high-output, 254 nm |
| UV Dose | ≥40 mJ/cm² Cryptosporidium; ≥186 mJ/cm² Adenovirus |
| Configuration | Closed-vessel pressure pipe / Open channel |
| Reactor | SS316L, flanged, PN10/16, Customized |
| Lamps per Unit | 4–32 amalgam lamps |
| UV Monitor | Validated online sensor |
| Lamp Life | 12,000 hours (amalgam) |
| Compliance | US EPA UVDGM, CE, ISO 9001:2015 |
- Amalgam lamps — 3× higher UV output, consistent across 5–40°C water temp
- 20,000–2,00,000 LPH from single skid
- CFD-validated reactor — guaranteed dose uniformity, no short-circuiting
- US EPA UVDGM compliant — Cryptosporidium 3-log, Giardia 3-log
- Open channel option — direct fit in existing STP/ETP channels
- 12,000 hour lamp life — lower annual operating cost
- CE certified, ISO 9001:2015
