UVGI AHU Disinfection System

Name: UVGI AHU Disinfection System
Brand: Ozone India Technology

UVGI UV germicidal irradiation system for AHU HVAC in-duct disinfection in hospitals and data centres

OZ India UVGI AHU Disinfection System installs UV-C lamps inside AHU and air handling units to kill airborne pathogens and prevent biofilm on cooling coils. ASHRAE 62.1 compliant, CE certified. For hospitals, data centres, hotels, airports. Ozone India Technology, Greater Noida.

UV Germicidal Irradiation (UVGI) systems installed inside Air Handling Units (AHU) and HVAC ductwork to continuously disinfect recirculating air and prevent microbial biofilm growth on cooling coils. Coil irradiation mode: lamps aimed at cooling coil surface prevent biofilm reducing energy consumption 10-25%. Air stream mode: high-intensity lamps in duct kill airborne pathogens in fast-moving air. Both modes combined for maximum effectiveness. Complies with ASHRAE 62.1 ventilation standard. Essential for hospitals, data centres, hotels, airports, and pharmaceutical manufacturing. CE certified, ISO 9001:2015.

Product Specifications for UVGI AHU Disinfection System
Installation	In-duct AHU coil irradiation or airstream
Lamp Configuration	Single double or multi-lamp arrays
UV Wavelength	254nm germicidal UV-C
Coverage	Custom to AHU cross-section area
Airflow Range	500 CFM to 100000 CFM
Coil Protection	Prevents biofilm 10-25 percent energy saving
Power Supply	220V AC 50Hz
Certification	CE, ISO 9001:2015, ASHRAE 62.1 compliant
