1 / 2Ozone Pipe - PVDF
PVDF ozone-resistant piping for connecting ozone generators to contact systems
OZ India Ozone Pipe in PVDF for ozone-resistant piping in water treatment systems. 0.5 to 6 inch diameter. Do not use PVC or rubber with ozone - only PVDF. CE certified. Ozone India Technology, Greater Noida.
CE & ISO 9001:2015 certified manufacturer · Est. 2014 · 150,000+ installations · Greater Noida, India
Ozone is a highly reactive oxidising gas that rapidly degrades standard PVC, rubber, and most plastics. The OZ India Ozone Pipe range uses only PVDF (Polyvinylidene Fluoride) - the material proven for long-term ozone service. PVDF pipes are lightweight, chemically resistant, and easy to install. Available in 0.5 inch to 6 inch diameter. Using incorrect piping materials in ozone systems causes rapid degradation and system failure - always specify ozone-rated materials.
| Materials Available | PVDF |
|---|---|
| Ozone Resistance | Full service - no degradation |
| Connections | Compression fittings |
| Certification | CE, ISO 9001:2015 |
- PVDF - only safe material for ozone piping
- Do not use PVC rubber or standard plastics with ozone
- PVDF - lightweight easy installation for above-ground runs
- All fittings and valves available in matching materials
INDUSTRY APPLICATIONS
Where OZ Ozone Pipe is Used
Related Products
Frequently Asked Questions
Ozone-compatible materials include PVDF (polyvinylidene fluoride), PTFE, 316L stainless steel, titanium, and silicone. Ozone attacks and degrades: PVC, natural rubber, neoprene, most plastics and elastomers, and copper (at concentrations above 0.3 mg/L). All Ozone India Technology accessories use PVDF or SS316L construction.
A venturi injector creates a low-pressure zone as water flows through the narrowed throat, drawing ozone gas into the water stream by the Venturi effect. The resulting micro-bubbles dissolve at 85–95% efficiency. The water must be at sufficient pressure (1–3 bar) and flow (matched to the injector's rated flow range) for effective ozone transfer.
Yes. All fittings used with PVDF ozone pipe must also be ozone-compatible — PVDF compression fittings or 316L stainless steel fittings are used. Standard PVC fittings must not be used with ozone pipework. All Ozone India Technology PVDF pipe and fittings are pre-certified for ozone compatibility.
Ozone India Technology static mixers are sized to match the ozone generator's sidestream or main water flow and are available for flow ranges from 0.5 m³/hr (50 mm pipe) to 100 m³/hr (200 mm pipe). Static mixers achieve >95% ozone dissolution efficiency when sized correctly for the water flow rate.
